Distillation Condensation Apparatus

Product Overview

The NJbinglab Distillation Condensation Apparatus is a customizable laboratory system designed for distillation, reflux, condensation, fractionation, and chemical reaction processes involving highly corrosive or contamination-sensitive media.

Constructed primarily from high-purity PFA and PTFE, the apparatus provides excellent chemical resistance and ultra-low extractables, making it particularly suitable for applications involving HF, HCl, HNO₃, aqua regia, mixed acids, and other aggressive chemicals.

The system can be configured according to specific experimental requirements, including the reaction vessel, distillation and condensation section, collection system, gas handling components, and connection structure.

Key Features

High Chemical Resistance

PFA and PTFE components provide excellent resistance to highly corrosive chemicals, including hydrofluoric acid, hydrochloric acid, nitric acid, aqua regia, and mixed acids.

Ultra-Low Contamination

High-purity fluoropolymer materials help minimize metal ion contamination and extractables, making the system suitable for high-purity chemical processing and trace-element analysis.

Highly Customizable

The complete apparatus can be customized according to process requirements, including vessel dimensions, condenser type, column size, connection method, and inlet/outlet positions.

Visual Process Monitoring

PFA components are semi-transparent, allowing convenient observation of liquid levels and process conditions during operation.

Modular Configuration

Individual components can be combined into an integrated system or adapted to existing reactors and laboratory setups.

Suitable for Corrosive Media

The fluoropolymer construction makes the apparatus particularly suitable for demanding applications where conventional glass or metal components may be unsuitable.

Available Configurations

Reaction Vessels/Reactor

Various PFA/PTFE reaction vessels, flasks, reactors, and containers can be integrated into the system according to the required capacity and process.

Distillation & Condensation Components

Different condensation and distillation configurations are available, including:

• Straight condensers
• Coil condensers (Graham condensers)
• PFA/PTFE cooling condensers
• PFA/PTFE fractionating columns
• Reflux and distillation assemblies
• Customized distillation sections

Collection & Gas Handling

The system can be equipped with:

• PFA reagent bottles
• Gas washing bottles
• Collection vessels
• Gas inlet/outlet assemblies
• Exhaust gas treatment components
• Tubing and connectors

Connection Options

Different connection structures can be provided according to the application:

• Threaded connections
• Ground-joint style connections
• Customized inlet/outlet positions
• Integrated or modular connections

Customization Options

The Distillation Condensation Apparatus can be engineered according to your specific process requirements.

Customization includes:

• Reaction vessel/ Reactor capacity and dimensions
• Condenser's volume and structure
• Fractionating column height and diameter
• Tubing and connector specifications
• Inlet and outlet positions
• Connection methods
• Reflux and distillation configuration
• Collection system
• Gas handling and exhaust treatment
• Integration with existing laboratory reactors

Applications

The apparatus is suitable for a wide range of laboratory processes, including:

• Chemical distillation
• Reflux reactions
• Fractional distillation
• Acid purification
• High-purity chemical preparation
• Corrosive chemical processing
• Trace-element sample preparation
• Fluoropolymer-compatible reaction processes
• Gas washing and collection

It is especially suitable for laboratories working with highly corrosive acids or applications where minimizing contamination and maintaining chemical purity are critical.

Typical Compatible Chemicals

• Hydrofluoric Acid (HF)
• Hydrochloric Acid (HCl)
• Nitric Acid (HNO₃)
• Aqua Regia
• Mixed Acids
• Other highly corrosive chemical media

Why Choose NJbinglab?

NJbinglab provides customized PFA/PTFE laboratory systems rather than only individual components. From reaction vessels and distillation columns to condensers, collection vessels, and gas handling systems, the complete setup can be designed around your specific experimental process.

Custom dimensions, configurations, connections, and assemblies are available upon request.

FAQ

Q: What's the lead time for orders?

A: Standard models ship in 7 working days; customized units require 15 working days or more(Depending on the level of complexity) after payment.

Q: Can I request a customized size?

A: Absolutely! We offer tailored attachments.

Q: How do you handle shipping and delivery?

A: We deliver goods efficiently via express services such as DHL, FedEx, and UPS, as well as various other methods including air and sea freight.

Q: How do I place an order?

A: Contact us via email or leaving a message for a quote, then confirm with a PO.
